Heavy edge milling machine, Processing bevel width:200mm

GMMA-200L Plate Edge Milling Machine introduction:

The GMMA - 200L is another upgrade of GIRET's edge milling machine products. It is a heavy - duty steel plate edge milling equipment. Two working modes are available: automatic movement of the machine or movement of the plate. The bevel angle can be adjusted arbitrarily from 0 to 90 degrees. The bevel width can reach 200 mm, and it can clamp plates with a thickness ranging from 8 to 150 mm.

GMMA-200L Portable Plate Edge Milling Machine technical parameters:

Power Supply: AC380V 50HZ or AC220V 50HZ/60HZ ro 415V 50HZ

Total Power: 6520W

Clamp Thickness: 10~150mm

Porcessing plate widht: >150mm（Plate Width > 2 * Bevel width）

Processing plate length: >400mm（When Bevel width<60mm）

Becel Angle: 0~90 degree

Bevel Width: 0~200mm

Net Weigth: 475kg

Special Functions: Auto clamping plate
