Economics type plate edge milling machine, feed speed 0~1500mm/min, can be process corbon steel

GMMA-60S Protable edge milling machine technical parameters

Power Supply：AC 380V  50HZ

Total Power：4520W

Feed Speed：0~1500mm/min（According to bevel depth and material）

Clamp Thickness：6~60mm

Clamp Width：＞80mm (Not processing edge)

Processing Length：＞300mm

Bevel Angle：0°~60°Adjustable

Single Bevel Width：0~20mm （Change according to material and angle）

Bevel Width：0~45mm（Change according to bevel angle）

Cutter Plate：φ63 mm

Cutter Qty：6pcs

Worktable Height：700~760mm

Travel Space：800*800mm

Net Weight：200kg

Gross Weight：255kg

Package Size：800*690*1140mm

From: GIRET CNC edge milling machine and Beveling machine

Website: http://www.manific.com.cn

Our Factory Provides:  CNC edge milling machine, HMI plate beveling machine, Table edge beveling machine, Plate bevelling machine, sheet bevelling machine, self-propelled bevelling machine, Stainless steel bevelling machine, Steel bevelling machine, Portable groove machine, handheld groove machine, portable groove machine, portable edge milling machine, Portable plate bevelling machine, Portable edge shearing machine, sheet beveling machine, plate welding grooves machine.
